AMS releases theTCS3410，一个组合的环境光/ RGB颜色和闪烁检测传感器，带有微小的2 mm x 1 mm占地面积，进一步扩展了客户选择，以便在其面向胶中和超窄的挡板智能手机上使用。
At just 0.5 mm high, the TCS3410 can easily fit in a waterdrop notch for the selfie camera or in the ultra-narrow bezel of a smartphone, helping manufacturers to realize designs that maximize the screen-to-body ratio and hence the viewable display area.
Smartphones which take advantage of the extended capabilities and improved performance of the TCS3410 can offer smoother and more responsive display-brightness management even in the most challenging low light conditions; superior camera performance with better white balancing and image color correction; and the elimination of artifacts in-camera images and videos induced by high frequency flickering from artificial light sources.
TCS3410具有高灵敏度，低噪音/绿色/蓝色/蓝色（RGB），清晰和闪烁的检测通道，高精度相关色温（CCT），以及级别的环境光测量到1MLUX。增加可调节增益高达4096x导致闪烁检测和环境光传感的优异低光性能。
Improvements in flicker detection capability have also extended the range of flicker frequencies detected up to 7kHz at up to 11-bit resolution.
通过提高的灵敏度和采样率，TCS3410使智能手机能够在较低光下检测具有更高频率的闪烁。
By completely re-engineering the circuit and package, AMS has also made it easier for smartphone manufacturers to accommodate the sensor in the bezel area. Increased pixel sensitivity means that the die area occupied by the photodiodes has been reduced with no loss of overall sensitivity compared to the earlier generation of ALS products. In the TCS3410, the photodiodes are also located at one end of the package, so that the area which needs to be exposed to ambient light, for instance in the camera aperture, can be as small as 0.28mm2.
Operating from a 1.8V supply, the TCS3410 features a configurable sleep mode for low average power consumption. The sensor includes an I2C接口以快速模式与主处理器通信，最高可达1Mbit / s。
The TCS3410 ambient light and flicker detection sensor are available to order in production volumes.
