新技术、新材料、新产品:反对tiTech will be bringing numerous innovations to the 2015 Hannover Messe trade fair, where it will have two stands this year. At the corporate stand in Hall 6 (Stand F18), it will be all about the process and materials expertise of the rubber and plastics specialist and its added-value partners. At Stand B18 in Hall 25, the focus will be on products such as drive belts, hoses, hose lines and air spring systems as part of the leading trade fair, Motion, Drive & Automation.
The Highlights from Hall 6
Highlights from the stand in Hall 6, which will bear the slogan “Engineering Next Level,” will include the SafeTrap scaffolding hatch; printed electronics, with which electric conductor paths can be printed cost-effectively; and a vehicle component made of plastic that opens up new performance classes. The SafeTrap scaffolding hatch has passed fall tests and is now being used for the first time by our development partner ALTRAD plettac assco, one of Germany’s leading one-stop suppliers of façade, modular, and mobile scaffolding systems. The self-closing, flexible scaffolding hatch offers maximum safety. Whereas conventional solutions are flexible only to a limited degree, SafeTrap is based on a combination of an aluminum profile and a vulcanized rubber layer with fabric reinforcement. Workers on scaffolding can open the hatch with their heads when climbing. This means that they do not have to put down tools, building materials, or other materials in order to open the hatch. The hatch then closes by itself or with a push from the worker’s foot.
印刷电子产品在行业中变得越来越重要。“印刷电子设备”一词包括通过打印过程制造的电子应用。作为印刷电子领域的Flexo印刷专家和全方位服务提供商，Contitech和Saueressig Flexo一起为客户提供了一种简单的访问该市场的方式。打印导电材料而不是打印墨水，从而生产RFID解决方案，传感器，显示器或太阳能电池。该行业的专家说，在Flexo印刷中进行具有成本效益，可持续和环保生产的机会远非疲惫。
ContiTech uses its expertise in lightweight construction to conquer other areas of application where metal once dominated. For the first time, the bearings specialist has developed a transmission crossbeam from fiberglass-reinforced polyamide BASF Ultramid for the rear axle, which is used in the Mercedes-Benz S-Class. The new variant is about 25 percent lighter compared with diecast aluminum versions, and represents a milestone in the use of polyamides in the chassis segment. It is used in Mercedes-Benz vehicle models with all-wheel drive – with the exception of the AMG range. The component boasts optimum strength, good NVH performance, and high crash-protection. As a central component of the rear axle, it supports forces and torques of the rear axle transmission.
A new engine mount made of halogen-free plastic, fire-retardant up to 220°C, provides greater safety around the house. Among other things, it meets the requirements of the U.S. fire protection standard UL 94 V0, which is identical in content to the European standards DIN EN 60695-11-10 and -20 and the Canadian standard CSA C 22.2. Further advantages for the appliance user: The domestic appliances are noticeably quieter when running due to the professional mounting. At the same time, wear and tear on components such as the drive train in the motor is reduced. This increases the service life of the domestic appliance. Maintenance periods and costs can be considerably reduced. The new ContiTech engine mount is already being used in high-end clothes dryers in the U.S.A.
The Highlights from Hall 25
The products on display in Hall 25 will include drive belts, hoses, hose lines, and air spring systems from ContiTech. ContiTech has broadened its range of eco-friendly drive belts marketed under the BlueConcept label. The label stands for environmentally compatible and healthful industrial applications. In the future, a timing belt will also be available for project business. The CONTI® SYNCHROBELT PIONEER contains no carbon black and is free of allergens, making it the alternative drive solution for the consumer goods industry. With the CONTI® POLYROPE, ContiTech has made further developments to the successful flat belt technology that was introduced to the elevator industry in the late 1990s. The CONTI® POLYROPE is certified according to the 95/16/EC Lifts Directive, and offers numerous advantages over conventional steel cord. The coating is abrasion-resistant and resistant to hydrolysis, and has excellent traction characteristics – reliable power transmission is ensured even at maximum load. The CONTI® POLYROPE is available in widths of 25 mm and 50 mm and with both a flat and a ribbed rear side.
现已在汽车场的串联生产中使用了带有导电衬里的燃油管线已有一段时间了。现在，对于工业车辆而言，该应用程序现在变得越来越有趣 - 尤其是由于美国的相关法规。由FPM（Flurooloromerymer Rubber）制成的导电内层可防止以高流量形成静态电荷，这是在高流量的情况下 -最坏的情况 - 可能导致飞机飞机和车辆的自发点火。CONTITECH的超燃燃料线适用于汽油，柴油和生物柴油，并永久承受-40°C至160°C的工作温度。持续温度为180°C的项目目前正在进行最终测试。
The CONTI® CLEANJET – FDA is the multi-purpose hose for the food industry and is suitable for both the thorough cleaning of machines and systems as well as for the hygienic processing of liquid foodstuffs containing oil and grease. Thanks to a specialized, highly resistant rubber compound, the CONTI® CLEANJET – FDA can even handle corrosive chicken fat. The robust brand-name hose also reliably delivers hot water up to a temperature of 80°C and an operating pressure of 90 bar, which sets this high-quality universal hose apart from all other cleansing and food hoses available on the market.
在过去的几年中，特殊的增值合作伙伴（WEP）展示已成为汉诺威·梅斯（Hannover Messe）的contitech存在的固定特征。Select供应商与Contitech在6号厅的展台上合作，展示了工业合作伙伴相互互动并在制造高质量产品时相互信任的重要性。他们还强调了最新的技术趋势。增值合作伙伴的技术从高性能塑料和织物扩展到机械工程中的系统解决方案。
