Hirose has launched a back flip FPC/FCC connector with increased retention force. The high FPC/FFC retention force in addition to the back flip design makes the FH34D Series ideal for curved routing of FPC/FFC.
FH34D系列具有简单，执行器锁，具有简单的两步操作，FH34D系列具有7.8 n的高FPC保持力，可用于顶部触点，14.5 n在底部触点上。这比竞争力的FFC / FPC连接器高3.6倍，带有4.0 n的保留力。通过增加FPC / FFC，FH34系列通过增加FPC布局选项提供设计灵活性。FH34D系列通过锥形壳体开口将高保持力与光滑的FPC / FFC插入相结合。
The space-saving FH34D series has a 0.5 mm pitch, 1.0 mm height, and a required mounting depth of only 3.2 mm. Designed to support USB 3.2 Gen 2, PCIe Gen 3, ePD 1.3 and MIPI D-PHY 1.1, the FH34D series is designed for consumer, medical, point-of-sale and other portable electronic applications.
The FPC connector is designed for automated pick-and-place assembly processes to simplify the manufacturing/assembly process.
“The FH34D Series FPC connector utilizes an advanced locking mechanism to securely hold the FPC tab in place, making it ideal for portable electronics that require curved routing of the FPC/FFC. Curved routing is commonly used for LED backlight connections in portable electronics,” said Mark Kojak, VP of Sales and Marketing for Hirose Electric USA.
It is available in a wide range of positions, from 4 to 50. The connector has a rated current of 0.5 A, a rated voltage of 50 Vac/dc, and a contact resistance of 100 milliohms max.
